VALIDATE® Urine Chemistry

15 Analytes
Human Urine Matrix
Liquid, Ready-to-Use

Analyte Summary

UC1:

CL,ETOH,GLU,K ,NA,UA,UTP,UUN

UC4:

CA,CREA,MG,PHOS

UC5:

µALB,AMY,PAMY

UC6:

µALB,CREA

Urine Chemistry

UC1

Analyte	Analyte Name	Units	Abbott ARCHITECT / ALINITY ORDER Nº 701ab TypicalRanges	Beckman Coulter AU ORDER Nº 701au TypicalRanges	Beckman Coulter Unicel DxC / Synchron ORDER Nº 701bc TypicalRanges	Siemens Dimension® ORDER Nº 701db TypicalRanges
Set 1
UA	Uric Acid	mg/dL	7.9 - 90	7.9 - 90	5 - 100	0 - 100
Set 2
CL	Chloride	mmol/L	24 - 282	19 - 395	15 - 300	10 - 375
ETOH	Ethyl Alcohol	mg/dL	21 - 544	12 - 600	5 - 600	3 - 300
GLU	Glucose	mg/dL	5 - 749	12 - 680	5 - 700	0 - 500
K	Potassium	mmol/L	3 - 272	3 - 200	2 - 300	1 - 300
NA	Sodium	mmol/L	26 - 377	10 - 385	10 - 300	5 - 300
UTP	Total Protein	mg/dL	14 - 178	5 - 200	6 - 150	6 - 250
UUN	Urea Nitrogen	mg/dL	66 - 1,835	22 - 1,300	50 - 1,000	0 - 1,500

Analyte	Analyte Name	Units	Roche cobas® ORDER Nº 701re* TypicalRanges	Roche COBAS INTEGRA® ORDER Nº 701ri TypicalRanges	Roche cobas® ORDER Nº 701ro TypicalRanges	Siemens Atellica® ORDER Nº 701sa TypicalRanges
Set 1
UA	Uric Acid	mg/dL	7.9 - 90	0.2 - 100	8 - 92	7.9 - 90
Set 2
CL	Chloride	mmol/L	60 - 350	20 - 350	27 - 241	19 - 300
ETOH	Ethyl Alcohol	mg/dL	17 - 510	10 - 498	17 - 510	6 - 270
GLU	Glucose	mg/dL	4 - 757	4.32 - 720	4 - 757	8 - 650
K	Potassium	mmol/L	3.3 - 109	1 - 150	4 - 107	6 - 275
NA	Sodium	mmol/L	66 - 352	20 - 350	26 - 236	18 - 277
UTP	Total Protein	mg/dL	6 - 200	4 - 200	6 - 200	11 - 185
UUN	Urea Nitrogen	mg/dL	20 - 5549	2.8 - 5,600	20 - 5,549	45 - 898

Analyte	Analyte Name	Units	Ortho VITROS® ORDER Nº 701vt TypicalRanges
Set 1
UA	Uric Acid	mg/dL	7.9 - 90
Set 2
CL	Chloride	mmol/L	17 - 280
GLU	Glucose	mg/dL	25 - 625
K	Potassium	mmol/L	3 - 168
NA	Sodium	mmol/L	16 - 238
UTP	Total Protein	mg/dL	0 - 180
UUN	Urea Nitrogen	mg/dL	75 - 2,439

UC1 Notes:

*This product is intended specifically for the Roche cobas® 8000 series. UC1 (701re) is not CE marked.

UC4

Analyte	Analyte Name	Units	Abbott ARCHITECT / ALINITY ORDER Nº 704ab TypicalRanges	Beckman Coulter AU ORDER Nº 704au TypicalRanges	Beckman Coulter Unicel DxC / Synchron ORDER Nº 704bc TypicalRanges	Siemens Dimension® ORDER Nº 704db TypicalRanges
CA	Calcium	mg/dL	3.3 - 22	0 - 38.6	2 - 30	5 - 15
CREA	Creatinine	mg/dL	7 - 667	1 - 292	10 - 400	5 - 400
MG	Magnesium	mg/dL	3.5 - 24	0.5 - 10	1 - 70	0 - 20
PHOS	Phosphorus	mg/dL	7 - 168	10 - 198	10 - 120	0 - 90

Analyte	Analyte Name	Units	Roche COBAS INTEGRA® ORDER Nº 704ri TypicalRanges	Roche cobas® ORDER Nº 704ro TypicalRanges	Siemens Atellica® ORDER Nº 704sa TypicalRanges
CA	Calcium	mg/dL	0.8 - 30.1	1 - 27.4	1.0 - 26.3
CREA	Creatinine	mg/dL	0.3 - 452	3 - 580	4.8 - 219.9
MG	Magnesium	mg/dL	1.8 - 30.4	2 - 25	2.2 - 12.9
PHOS	Phosphorus	mg/dL	3.41 - 285	4 - 275	7 - 87

UC5

Analyte	Analyte Name	Units	Abbott ARCHITECT / ALINITY ORDER Nº 705ab TypicalRanges	Beckman Coulter AU ORDER Nº 705au TypicalRanges	Beckman Coulter Unicel DxC / Synchron ORDER Nº 705bcc TypicalRanges	Siemens Dimension® ORDER Nº 705db TypicalRanges
µALB	Micro-Albumin	mg/L	---	11 - 425	6 - 290	1.3 - 100
µALB	Micro-Albumin	µg/mL	8 - 430	---	---	---
AMY	Amylase	U/L	8 - 6,150	15 - 1,500	9 - 1,140	0 - 650
PAMY	Pancreatic Amylase	U/L	---	---	---	0 - 650

Analyte	Analyte Name	Units	Roche COBAS INTEGRA® ORDER Nº 705ri TypicalRanges	Roche cobas® ORDER Nº 705ro TypicalRanges	Ortho VITROS® ORDER Nº 705vt TypicalRanges
µALB	Micro-Albumin	mg/L	12 - 200	14 - 395	7 - 177
AMY	Amylase	U/L	3 - 2,000	3 - 1,430	42 - 1,140
PAMY	Pancreatic Amylase	U/L	3 - 1,500	3 - 1,430	---

UC5 Notes:

UC5au: Test kits also contain PAMY as part of the AMY component.
UC5bcc: Test kits also contain PAMY as part of the AMY component.
UC5ri: Assay Levels 1 through 4 only for PAMY. Level 5 will typically recover above the reportable range.

UC6

Analyte	Analyte Name	Units	Alere Afinion™ ORDER Nº 706af TypicalRanges
Set 1
µALB	Micro-Albumin	mg/L	5 - 200
Set 2
CREA	Creatinine	mg/dL	16.4 - 339.9

Typical ranges or recommended Level usage for products are intended as a guide only.

The Quality System for LGC Clinical Diagnostics, Inc. is registered to ISO 13485:2016 by DEKRA Certification B.V.
® 2001- 2023 VALIDATE is a registered trademark of LGC Clinical Diagnostics, Inc.
LGC Maine Standards is a brand name for LGC Clinical Diagnostics, Inc.
